Celestion CDX1-1730 Compression Driver
$259.00
Brand Name:
Celestion
Product Description
Celestion CDX1-1730
1" HF Driver 8 Ohm
Features:
- 1" exit, neodymium magnet compression driver with 1.75" edgewound copper clad aluminium voice coil
- 40W rms (AES standard) power handling and 110dB sensitivity
- Designed with Sound Castle™ clamping to ensure uniform pressure on diaphragm assembly for reduced acoustic distortion
- One piece PETP film diaphragm and surround
- Advanced Finite Element Analysis (FEA) tools used to create a very light weight, high powered compression driver
General Specifications
- Power rating140Wrms
- Nominal impedance 8Ω
- Frequency range 1200-20,000Hz
- Sensitivity2 110dB
- Recommended min. crossover (12dB/oct) 2200Hz
- Voice coil diameter 44mm/1.75in
- Voice coil material Edgewound copper clad aluminium
- Magnet type Neodymium
- Diaphragm material PETP film
- Surround material PETP film
Mounting Information
- Overall depth55mm
- Fitting Flange (4 x M6 holes on 76mm/3in PCD)
- Throat exit 25.4mm
- Maximum width 88.5mm
- Minimum width 82.0mm
- Unit weight 0.65kg
Packed Dimensions & Weight
- Single pack size 90mm x 90mm x 60mm
- Single pack weight 0.75kg.
Crossfader are Authorised Celestion Australia Dealers.
